Domain management 35
o
Administer SSL certificates
o Delete the VC domain
o Save configuration to disk
o Restore the configuration from a backup
o Configure SNMP settings
• Networking
o Configure network default settings
o Select the MAC address range to be used by the VC domain
o Create, delete, and edit networks
o Create, delete, and edit shared uplink sets
o Configure Ethernet SNMP settings
• Server
o Create, delete, and edit server Virtual Connect profiles
o Assign and unassign profiles to device bays
o Select and use available networks
o Select serial numbers (logical) and UUIDs (logical) to be used by server profiles
o Power on and off server blades within the enclosure
• Storage
o Select the WWNs to be used by the domain
o Set up the connections to the external FC Fabrics
o Configure FC SNMP settings
It is possible to create a user with no privileges. This user can only view status and settings.
NOTE: The vcmuser_ account is an internal Onboard Administrator account created and used
by Virtual Connect Manager to communicate with the Onboard Administrator. This account
can show up in the Onboard Administrator system log. This account cannot be changed or
deleted.
