Hardware information screens 154
Row Description
Enclosure Name Name of the enclosure where this server blade is installed
UID Icon indicates whether the UID is illuminated or not illuminated.
Power Status/Control Icon indicates whether the server blade in that bay is powered on or off.
The following table describes the rows within the Server Blade Information table in the Server Bay Status
screen.
Server Blade Information
Row Description
Serial Number The unique serial number of the server blade
Product Name The common descriptive name of the server blade
Server Name If configured, the server name of the installed server blade
Part Number
The part number to be used when ordering an additional or replacement
server blade of this type
Asset Tag If configured, the asset tag of the installed server blade
Monarch Bay (multi-blade
servers only)
Identifies the monarch bay in the multi-blade server
All Bays (multi-blade servers
only)
Identifies all of the bays in the multi-blade server
The following table describes the columns within the Server Ethernet Adapter Information table in the
Server Bay Status screen.
Server Ethernet Adapter Information
Column Description
Device Bay Identifies the bay whose ports are shown in that group
Ethernet adapter Port number where the adapter is installed
Flex NIC Flexible network interface port
Location Connection location of this adapter
Model Type of adapter installed
MAC Address MAC address of the Ethernet adapter
Network Network name associated with this adapter
Connected to Bay number
The following table describes the columns within the SAN Ports table in the Server Bay Status screen.
SAN Ports
Column Description
Device Bay Identifies the bay whose ports are shown in that group
