Hardware information screens 152
The following table describes the columns within the Server Ethernet Adapter Information table in the
Server Bay Status screen.
Server Ethernet Adapter Information
Column Description
Ethernet adapter Port number where the adapter is installed
Flex NIC Flexible network interface port
Location Connection location of this adapter
Model Type of adapter installed
MAC Address MAC address of the Ethernet adapter
Network Network name associated with this adapter
Connected to Bay number
The following table describes the columns within the SAN Ports table in the Server Bay Status screen.
SAN Ports
Column Description
Port Number Relative Fibre Channel Port number
Adapter Mezzanine number where the HBA is connected
Model Type of mezzanine installed
WWN VC-Assigned WWN or "Server Factory Default" if not assigning WWNs
Connected to Bay number
