Hardware information screens 148
Server Bay Overall Status icon definitions
Icon Operational state Meaning Corrective action
OK Device is fully operational. None
Unknown
Device operational state cannot
be determined.
Check Onboard Administrator
communication.
(blue)
Initializing Device is initializing.
Wait until initialization is complete.
(This icon should only be seen at
startup.)
(blue)
Profile pending
Device has a pending profile
assignment.
Turn server power off and apply the
new profile.
(yellow)
Degraded
Device is partially operational,
but capacity is lost.
Check and correct the Onboard
Administrator error condition.
(orange)
Misconfigured Device has a configuration error.
Correct the Virtual Connect Manager
configuration attributes.
(orange)
Incompatible
Device does not match the
configuration.
BIOS version level is not at a level
that supports Virtual Connect.
(orange)
No communication
Cannot communicate with the
device.
Check the physical connections and
IP address.
(orange)
Missing data
VCM is missing data about one
or more blades in the multi-blade
server.
Check that the blades and SBL that
comprise the multi-blade server are
installed correctly and functioning
properly.
Missing
Device is configured but not
accessible.
Insert the correct hardware module.
Failed
Device is not operational because
of an error.
Reset the device or application, or
replace the device.
Server Bay OA Reported Status icon definitions
Icon Operational state Meaning Corrective action
OK Device is fully operational. None
Unknown
Device operational state cannot
be determined.
Check Onboard Administrator
communication.
(yellow
)
Degraded
Device is partially operational,
but capacity is lost.
Check and correct the Onboard
Administrator error condition.
Failed
Device is not operational because
of an error.
Check and correct the Onboard
Administrator error condition.
Server Bay VC Status icon definitions
Icon Operational state Meaning Corrective action
OK Device is fully operational. None
