Hardware information screens 143
Interconnect Bay Overall Status icon definitions
Icon Operational state Meaning Corrective action
OK Device is fully operational. None
Unknown
Device operational state cannot
be determined.
Check Onboard Administrator
communication.
(blue)
Initializing Device is initializing.
Wait until initialization is complete.
(This icon should only be seen at
startup.)
(yellow)
Degraded
Device is partially operational,
but capability is lost.
Check and correct the Onboard
Administrator error condition.
(orange)
Misconfigured Device has a configuration error.
Correct the Virtual Connect Manager
configuration attributes.
(orange)
Incompatible
Device does not match the
configuration.
Remove the incorrect hardware.
Insert the correct module.
(orange)
No communication
Cannot communicate with the
device.
Check the physical connections and
IP address.
Missing
Device is configured but not
accessible.
Insert the correct hardware module.
Failed
Device is not operational because
of an error.
Reset the device or application, or
replace the device.
Interconnect Bay OA Reported Status icon definitions
Icon Operational state Meaning Corrective action
OK Device is fully operational. None
Unknown
Device operational state cannot
be determined.
Check Onboard Administrator
communication.
(yellow
)
Degraded
Device is partially operational,
but capacity is lost.
Check and correct the Onboard
Administrator error condition.
Failed
Device is not operational because
of an error.
Check and correct the Onboard
Administrator error condition.
Interconnect Bay VC Status icon definitions
Icon Operational state Meaning Corrective action
OK Device is fully operational. None
Unknown
Device operational state cannot
be determined.
Check Onboard Administrator
communication.
Disabled
User has administratively
disabled the device.
Enable the component in Virtual
Connect Manager.
(blue)
Initializing Device is initializing.
Wait until initialization is complete.
(This icon should only be seen at
startup.)
