Hardware information screens 138
Port Statistic Description
IfHCOutBroadcastPckts
The total number of packets that higher-level protocols requested be
transmitted, and which were addressed to a broadcast address at this
sublayer, including those that were discarded or not sent. This object is
a 64-bit version of ifOutBroadcastPkts.
Remote Device Information Description
remote_type
Type of remote device. Virtual Connect uses this information to
configure the link as an uplink, a stacking link, or to disable. This
information is based on the LLDP data sent by the device to which the
port is attached.
remote_discovered_time
Time the remote device was identified, represented in seconds. This
information is based on the LLDP data sent by the device to which the
port is attached.
remote_chassis_id_type Chassis ID subtype of the remote device.
remote_chassis_id Chassis ID value of the remote device.
remote_port_id_type Port ID subtype of the remote device.
remote_port_id Port ID value of the remote device.
remote_port_desc Port description of the remote device.
remote_system_name
System name of the remote device. If the remote device is a VC-Enet
module, remote_system_name is the remote device's VC domain
name.
remote_system_desc
Description of the remote system. If the remote device is a VC-Enet
module, remote_system_desc is the module's hardware description and
firmware revision.
remote_system_capabilities
System capabilities of the remote system, for example, repeater,
bridge, or router.
remote_mgmt_addr_type
Management address subtype of the remote device, for example, IPv4,
IPv6, or DNS.
remote_mgmt_addr Management address of the remote device.
