Hardware information screens 137
Port Statistic Description
Dot3StatsSymbolErrors
For an interface operating at 100 Mb/s, the number of times an
invalid data symbol occurred when a valid carrier was present. For an
interface operating in half-duplex mode at 1000 Mb/s, the number of
times the receiving media is non-idle (a carrier event) for a period of
time equal to or greater than slotTime, and during which there was at
least one occurrence of an event that causes the PHY to indicate 'Data
reception error' or 'carrier extend error' on the GMII.
For an interface operating in full-duplex mode at 1000 Mb/s, the
number of times the receiving media is non-idle (a carrier event) for a
period of time equal to or greater than minFrameSize, and during
which there was at least one occurrence of an event that causes the
PHY to indicate 'Data reception error' on the GMII. The count
represented by an instance of this object is incremented, at most, once
per carrier event, even if multiple symbol errors occur during the
carrier event. This count does not increment if a collision is present.
Dot3ControllnUnknownOpcodes
A count of MAC Control frames received on this interface that contain
an opcode that is not supported by this device.
Dot3InPauseFrames
A count of MAC Control frames received on this interface with an
opcode indicating the PAUSE operation. This counter does not
increment when the interface is operating in half-duplex mode.
Dot3OutPauseFrames
A count of MAC Control frames transmitted on this interface with an
opcode indicating the PAUSE operation. This counter does not
increment when the interface is operating in half-duplex mode.
IfHCInOctets
The total number of octets received on the interface, including framing
characters. This object is a 64-bit version of ifInOctets.
IfHCInUcastPkts
The number of packets, delivered by this sublayer to a higher sublayer,
which were not addressed to a multicast or broadcast address at this
sublayer. This object is a 64-bit version of ifInUcastPkts.
IfHCInMulticastPkts
The number of packets, delivered by this sublayer to a higher sublayer,
which were addressed to a multicast address at this sublayer. For a
MAC layer protocol, this includes both Group and Functional
addresses. This object is a 64-bit version of ifInMulticastPkts.
IfHCInBroadcastPkts
The number of packets, delivered by this sublayer to a higher sublayer,
which were addressed to a broadcast address at this sublayer. This
object is a 64-bit version of ifInBroadcastPkts.
IfHCOutOctets
The total number of octets transmitted out of the interface, including
framing characters. This object is a 64-bit version of ifOutOctets.
IfHCOutUcastPkts
The total number of packets that higher-level protocols requested be
transmitted, and which were not addressed to a multicast or broadcast
address at this sublayer, including those that were discarded or not
sent. This object is a 64-bit version of ifOutUcastPkts.
IfHCOutMulticastPkts
The total number of packets that higher-level protocols requested be
transmitted, and which were addressed to a multicast address at this
sublayer, including those that were discarded or not sent. For a MAC
layer protocol, this includes both Group and Functional addresses. This
object is a 64-bit version of ifOutMulticastPkts.
