Hardware information screens 130
Column Description
Label Uplink port number
Network(s) Network name or the name of the shared uplink associated with this port
Status Displays whether the port is linked or unlinked
Connector Type
Displays the physical type of the faceplate connector, type of pluggable
module if one is present, or "Internal" to indicate the inter-switch link is
active on the VC-Enet module.
LAG ID
Identifies the group of ports that have been aggregated together to form an
802.3ad Link Aggregation Group. This ID is unique only within a single
VC-Enet module, meaning the same LAG ID can be used on different VC-
Enet modules, but it is only meaningful for ports within the same VC-Enet
module.
Connected to
Displays the MAC address of the device that this port is connected to on
the other end. The device must support LLDP to display this information
Detailed Statistics Click to display detailed statistics about this port.
The following table describes the columns within the Server Port Information table in the Bay Summary
screen.
Column Description
Label Server side port number (determined by the device bay and NIC)
Flex NIC Flexible network interface port
Physical server Number of the device bay and a description of the installed server blade
Network Network name or the name of the shared uplink associated with this port
Profile Name of the server blade profile
Status Displays whether the server blade is linked or unlinked
Detailed Statistics Click to display detailed statistics about this port
Port Detailed Statistics screen
This screen provides details on Port Information, Port Status, Port Statistics, and Remote Device
Information.
To reset the statistics, click Reset Statistics.
