Hardware information screens 125
Enclosure Status screen
When a VC domain loses connectivity with a remote enclosure OA, the Enter OA Credential button
appears on this screen. For additional information, see "Recovering remote enclosures. ("Recovering
remote enclosures" on page 21)"
The following table describes the rows within the Enclosure Status screen.
Row Description
Overall Status
Represents the most severe condition of hardware status, VC status, and
OA communication status
Hardware Status Enclosure health status from the OA
VC Status Enclosure health status from the Virtual Connect Manager
OA Communication Status
Current Virtual Connect Manager to Onboard Administrator
communication state
