Instruction Manual
Table Of Contents
- UImproperly installed or installed by someone other than a qualified, licensed auto mechanic experienced in the installation and removal of suspension products;
- UImproperly serviced, misused, or modified, altered or subjected to abuse, negligence, accident or collision;
- UInstalled in any vehicle that has been modified;
- UInstalled on any vehicle that has carried loads in excess of automobile manufacturer suggested weight limits; or
- UInstalled on any vehicle that has been subject to abnormal or excessive use, including rallying, racing, or racing-type activities or off-road use.
- UDid you register the product at U0TUwww.hotchkis.netU0TU or via the mail-in warranty card within 30 days of purchase?
- UIs the product appropriate to your application?
- UDid you carefully and thoroughly read the instructions provided along with the product?
- UDo you have the original invoice or sales receipt?
- UIs the return date within 36 months from the purchase date?
- UAre you the original purchaser?
- UWas the product properly installed by a qualified, licensed auto mechanic?
- UHas the product been installed on the original vehicle on which it was installed at all times?
- UIs the product unmodified and clean?
- UIs the reason for return a legitimate product defect?
P/N 1314
65-70 Chevrolet B-Body Lower Trailing Arm Kit, Parts List
Hotchkis P/N Item Description
Quantity
Per Kit
1 13910006 Lower Trailing Arm Body, 65-70 Chevy B-body 2
2 2255G Trailing Arm Bushing, 65-70 Chevy B-body 8
3 16410006 Trailing Arm Bushing Sleeve, 65-70 Chevy B-body 4
4 3/8SAEG8WASH 3/8" Flat Washer 2
5 3/8-16X1.0" 3/8" Bolt, Hex Head 2
6 13410006 Spring Retainer Plate, 65-70 Chevy B-body 2
7 7203 Grease Fitting, Tall 4
8 GC-5B Grease Cap, Black 4
9 5/16-18X4HEX 5/16" x 3/4" Bolt, Hex Head 2
10 5/16AN 5/16" Flat Washer 2
11 5/8-18X4HEX 5/8" x 4" Bolt, Hex Head 4
12 5/8 SAE 5/8" Flat Washer 8
13 5/8-18NYLOCK 5/8" Nylock Hex Nut 4
14 9.11108 Grease Pack 1
15 n/a Instruction Set 1
Hardware Included in Kit 1736 (one per kit 1314)
Items Not Shown
CHECK OUT EVERYTHING ELSE HOTCHKIS PERFORMANCE MAKES FOR YOUR 65-70 B-BODY CHEVROLET!!
• Tubular sway bar sets!
• Double adjustable panhard rod
to center your axle!
• Double adjustable trailing arms
to reduce driveline vibration!
Visit Hotchkis Performance on the web at www.Hotchkis.net or
Call (562) 907-7757 to order!
