7. Removal and Replacement of Evaporator
IMPORTANT
Always install a new drier every time the sealed refrigeration system is opened. Do not
replace the drier until after all other repair or replacement has been made.
1) Turn off the power supply.
2) Remove the panels and the top insulation over the evaporator.
3) Recover the refrigerant and store it in an approved container.
4) Remove the spray tubes and the insulations at the “U” shaped notch where the refrigeration
tubings go through the molded chassis.
5) Remove the insulation tube and disconnect the evaporator inlet tubing at the tee next to the
expansion valve.
6) Lift up the evaporator, and disconnect the evaporator outlet tubing.
7) Install the new evaporator.
8) Install the new drier.
9) Check for leaks using nitrogen gas (140 PSIG) and soap bubbles.
10) Evacuate the system, and charge it with refrigerant. For air-cooled and water-cooled models,
see the nameplate for the required refrigerant charge. For remote air-cooled models, see the
charge label in the machine compartment.
11) Replace the removed parts in the reverse order of which they were removed.
12) Replace the top insulation and the panels in their correct positions.
13) Turn on the power supply.
13) Replace the panels in their correct positions.
14) Turn on the power supply.
