Service Manual

12
NOTICE
• Normal operating ambient temperature range is from 60°F to 86°F
(15°C to 30°C).
• Ventilation is required from the bottom front of the appliance. Keep this
area open and clear of any obstructions. Adjacent cabinets and counter
top can be installed around the appliance as long as the front grille
remains unobstructed.
• The appliance must not be located next to ovens, grills, or other high
heat producing equipment.
• The appliance must not be located in a corrosive environment.
The diagnostic table is a sequence check that allows you to diagnose the electrical
system and components. Before proceeding, check for correct installation and proper
voltage per nameplate. Always choose a neutral (W) to establish a good neutral
connection when checking high voltages.
IMPORTANT
The maximum allowable voltage variation is ±10 percent of the nameplate rating.
115VAC is used as a reference voltage when checking voltage to components.
Voltage may vary depending on power supply.
Factory Default Temperature Setpoint:
RM-7-HC, RM-10-HC, RM-26-HC, RM-49-HC, RM-65-HC
35°F (1.66°C)
RM-45-SD-HC
35.6°F (2°C)
Temperature Display Scale: °F (°C)
• There is a minimum 3-min. Comp on time and 3-min. Comp off time.
