Specifications Sheet

Item #:
Project:
Qty:
AIA#:
618 Hwy, 74 S., Peachtree City, GA 30269 | TEL [phone] | FAX [phone] | www.hoshizakiamerica.com
© HOSHIZAKI AMERICA, INC.
* approximate size in inches, image not to scale
Features
• Up to 295 lbs. of ice production per 24 hours
• Built-in storage capacity of 3.3ft
3
/100 lbs.*
• Durable stainless steel exterior
• Front-in, front-out airflow
• Removable air filter (Air-cooled model only)
• Ice bin opening is ADA compliant
• 6 ft. (1800 mm) power cord with NEMA 5-15P plug
• H-GUARD Plus Antimicrobial adds extra protection
to the ice scoop (included)
• EverCheck
TM
alert system
• R-404A Refrigerant
Air-Cooled
Shown
KM-300BAJ
Individual crescent cube
Stainless steel evaporator
CycleSaver
TM
design
TM
TM
• Ambient Temp Range 45 - 100°F
• Water Temp Range 45 - 90°F
• Water Pressure 10 - 113 PSIG
• Voltage Range 104 - 127V
Operating Limits
• Icemaker Water Supply Line: Min.1/4” Nominal ID Copper Water Tubing
or Equivalent
• Icemaker Drain Line: Min. 3/4” Nominal ID Hard Pipe or Equivalent
Water-Cooled Model (Lines Must Be Independent of Icemaker)
• Condenser Water Supply Line: Minimum 1/4” Nominal ID Copper Water
Tubing or Equivalent
• Condenser Drain/Return Line: Min. 1/4” Nominal ID Hard Pipe (open drain
system) or Copper Water Tubing (closed loop system) or Equivalent
Plumbing
Service
30" x 28" x 39”*
W x D x H
Hoshizaki reserves the right to change specifications without notice.
Printed in the U.S.A.
*including 6” legs
Warranty:
3 Year Parts & Labor on entire machine. 5 Year Parts & Labor on Evaporator.
5 Year Parts on Compressor; air-cooled condenser coil.
Valid in United States, Canada, Puerto Rico and U.S. Territories. Contact factory for
warranty in other countries.
Water-Cooled
KM-300BWJ
295
265
KM-300BAJ
KM-300BWJ
Air-Cooled
210
230
7.02
4.90
22.0
20.0
N/A
95.4
15A
15A
Water-Cooled
4,200
4,050
115V/60/1
115V/60/1
Air / Water Temp
Lbs. per 24 hours
Condenser
Model
70°/ 50°F 90°/ 70°F
ICE PRODUCTION
Potable
Gal. per 100 lbs.
Condenser
Gal. per 100 lbs.
Max. Fuse Size
or HACR
Circuit Breaker
Heat
Rejection
BTU/hr.
Voltage
WATER USAGE
90°/ 70°F 90°/ 70°F
ELECTRICAL
90°/ 70°F
kWh Used
per 100 lbs.
Amperage
8.4A
5.7A
KM-300B_J
SELF-CONTAINED CUBER
WITH BUILT-IN STORAGE BIN
KM-300B_J
05/10/18
Item # 13235
• Allow enough space at rear for water supply and
drain connections. Allow at least 2” (5 cm) on right
side for proper air circulation and at least 0.6” (15
mm) clearance at top for service/maintenance.
1
1/2
”
1/2
”
1
1/8
”
KM Edge Cube Dimensions*
KMEdge
DESIGN
Please refer to water filter spec sheet for recommended configurations.
Water Filter
154 / 187
154 / 187
Net / Ship
Weight (lbs.)
13.4 oz.
12.3 oz.
Refrigerant
Charge Amount
Power cord included
ADA Compliant
