B. Dimensions/Connections

Unit: mm [inches]

ADJUSTABLE LEGS

149

[ 5 - 7/8 ]

785

[ 30 - 7/8 ]

665

[ 26 - 1/8 ]

225

[ 8 - 7/8 ]

607

[ 23 - 7/8 ]

307

[ 12 - 1/8 ]

700

[ 27 - 1/2 ]

852

[ 33 - 1/2 ]

1004

[ 39 - 1/2 ]

314

[ 12 - 3/8 ]

600

[ 23 - 5/8 ]

86

[ 3 - 3/8 ]

230

[ 9 ]

185

[ 7 - 1/4 ]

POWER SUPPLY CORD

1.8 m [ 5 ft. 8 - 1/2 ] LONG

WATER INLET

1/2" FPT

71

[ 2 - 3/4 ]

82

[ 3 - 1/4 ]

WATER DRAIN

3/4" FPT

93

[ 3 - 5/8 ]

22

[ 7/8 ]

AIR OUT

AIR IN
