Instruction Manual

2. Drain the water tank:
1) Move the control switch to the "OFF"
position and then unplug the appliance.
2) Remove the top panel, top insulation, and
top sheet.
3) Remove the screw and then move the tank
drain pipe to the drain position. See Fig. 6.
4) Replace the top sheet, top insulation, and
top panel.
5) Close the icemaker water supply line drain
valve.
6) Plug in the appliance and then move the
control switch to the "ICE" position.
7) Press the "RESET" button. See Fig. 7. The
water tank will start to open.
Note: This procedure is necessary to protect
the appliance from freezing up at sub-
freezing temperatures.
8) Move the control switch to the "OFF"
position and then unplug the appliance
when the water tank is fully opened.
9) Remove the top panel, top insulation, and
top sheet.
10) Move the tank drain pipe to the normal
position and then secure it with the screw.
See Fig. 6.
11) Replace the top sheet, top insulation, top
panel, and front panel.
Fig. 7
Fig. 6
[Normal Position]
[Drain Position]
Screw
Tank Drain
Pipe
23
