Parts List

Title: D. Water Circuit Model: C-80BAJ, C-80BAJ-DS, C-80BAJ-AD, C-80BAJ-ADDS
Index
No. Description
Material or
Model Number Part Number
Required Number
G-0
H-0
1 Water Supply Pipe 4A5216G05 1
2 Rubber Gasket 413854-03 1
3 Inlet Water Valve 4A5251-05 1
4 Reservoir 2A6586-01 1
5 Float Switch 435490-01 1
6 Reservoir Cover 3A6698-01 1
7 Overow Hose L=220 mm 7730-1216 1
8 Reservoir Inlet Hose 4A5388-01 1
9 Drain Valve 4A5530-03 1
10 Drain Fitting 4A3488G01 1
11 Vinyl Hose L=25 mm 7725-1923 1
12 Silicone Hose L=20 mm 7730-1519 1
13 Reservoir Outlet Hose 3A7565-01 1
14 Drain Hose 3A7521-01 1
15 Drain Pan (Gear Motor) 323765G01 1
16 Vinyl Cap 4A4370-01 1
Hose Clamps
Hose Clamp 25 mm 427443-03 1
Hose Clamp 27 mm 427443-08 1
Hose Clamp 17-21 mm 4A2017-05 1
Hose Clamp 22-25 mm 4A2017-09 1
