Parts List

Title: C. Icemaking Unit Model: C-80BAJ, C-80BAJ-DS, C-80BAJ-AD, C-80BAJ-ADDS
Index
No. Description
Material or
Model Number Part Number
Required Number
G-0
H-0
1 Gear Motor 2U0147-01 1
1a Socket Head Cap Screw 8×95, SS 7S12-0895 2
1b Split Lock Washer M8, SS 7L22-0800 2
2 Spline Coupling 418316-01 1
3 Housing 383613G01 1
3a Hex Head Bolt 6×20, SS 4A1989-01 4
4 O-Ring 4A4755-01 1
5 Mechanical Seal 432491-01 1
6 Ring 432494-01 1
7 Evaporator 364138G01 1
7a Split Lock Washer M6, SS 7L22-0600 4
7b Socket Head Cap Screw 6×10, SS 7S12-0610 4
8 Drip Pan 2A4118-01 1
9 Evaporator Flange 4A5075-01 1
10 Extruding Head 364141G03 1
10a Seal Bolt M8, SS P01768-02 3
11 Auger 269911G01 1
12 Cutter 4A5505-01 1
8
