Title: A. Main Assembly Model: C-80BAJ, C-80BAJ-DS, C-80BAJ-AD, C-80BAJ-ADDS

Index

No. Description

Material or

Model Number Part Number

Required Number

G-0

H-0

Main Assembly

1 Front Panel C-80BAJ

C-80BAJ-DS

3X6433-01 1

C-80BAJ-AD

C-80BAJ-ADDS

3X6433-02 1

2 Louver 2H5560-01 1

3 Top Panel 2A2849G01 1

4 Lower Louver Rear Panel C-80BAJ

C-80BAJ-DS

2A6345-01 1

C-80BAJ-AD

C-80BAJ-ADDS

2A5915-01 1

5 Spout 2A6636-01 1

5a Thumbscrew 415949G12 3

6 Packing 427151-01 1

7 Thermostatic Bin Control Bulb

Holder

3X6381-01 1

7a Thumbscrew 415949G10 2

8 Thermostatic Bin Control 3A2561A03 1

9 Slope 3X6383-01 1

10 Scoop Holder 4Y0213-01 1

10a Thumbscrew 415949G10 2

11 Hinge A C-80BAJ

C-80BAJ-AD

4Y0194G01 1

Right Hinge A C-80BAJ-DS

C-80BAJ-ADDS

4A4885G01 1

11a Hinge A Bracket 4A2996-01 1

12 Hinge B C-80BAJ

C-80BAJ-AD

4Y0192-01 1

C-80BAJ-DS

C-80BAJ-ADDS

4A3980-01 1

12a Flat Head Screw 4×12, SS 7C22-0412 2

13 Hinge Stop Pin 4A2180-01 1

14 Tooth Washer M6, SS 7R22-0600 1

15 Leg 4A2966-01 4

16 Control Box Cover C-80BAJ

C-80BAJ-DS

4A5267-01 1

C-80BAJ-AD

C-80BAJ-ADDS

4A4498-01 1

17 Power Supply Cord 4A2860-01 1
