Instruction Manual

MAN0970-04-EN RCC972 Specifications / Installation
Register Map
5 Filter
Filter Constant sets the level of digital filtering according to the
following chart
Digital Filtering module response to a temperature change. The
illustration above demonstrates the effect of digital filtering (set
with Filter Constant) on
8 Safety
When found on the product, the following symbols specify:
9 Technical Support
For assistance and manual updates, contact Technical Support at the following locations:
Digital
RCC972
V+
DC Power In
V+
24V DC Out
C
0V
Q4
Digital Ou4
Q3
Digital Ou3
Q2
Digital Out2
Q1
Digital Out1
C
0V
I8
Digital In8
I7
Digital In7
I6
Digital In6
I5
Digital In5
I4
Digital In4
I3
Digital In3
I2
Digital In2
I1
Digital In1
Registers Description
%I1 to %I8
Digital Inputs
%I9 to %I15
Reserved
%I16
%Q Fault Status
%Q1 to %Q4
Digital outputs
%AI1 to %AI8
Analog inputs
%AQ1 to %AQ4
Analog outputs
North America:
[phone]
www.heapg.com
email: [e-mail]
Europe:
(+) 353-21-4321-266
www.horner-apg.com
email: [e-mail]
 All applicable codes and standards need to be followed in the installation of this product.

Adhere to the following safety precautions whenever any type of connection is made to the
module:

Connect the safety (earth) ground on the power connector first before making an
y other
connections.

When connecting to electric circuits or pulse-initiating equipment, open their related breakers.

Do not make connections to live power lines.

Make connections to the module first; then connect to the circuit to be monitored.

Route power wires in a safe manner in accordance with good practice and local codes.

Wear proper personal protective equipment including safety glasses and insulated gloves when
making connections to power circuits.

Ensure hands, shoes, and floor are dry before making any connection to a power line.

Make sure the unit is turned OFF before making connection to terminals.

Make sure all circuits are de-energized before making connections.

Before each use, inspect all cables for breaks or cracks in the
insulation. Replace immediately
if defective.
•
Use Copper Conductors in Field Wiring Only, 60/75° C
WARNING: To avoid the risk of electric shock or burns, always connect the safety (or earth)
ground before making any other connections.
WARNING: To reduce the risk of fire, electrical shock, or physical injury it is strongly
recommended to fuse the voltage measurement inputs. Be sure to locate fuses as close to the
source as possible.
WARNING: Replace fuse with the same type and rating to provide protection against risk of fire
and shock hazards.
WARNING: In the event of repeated failure, do not replace the fuse again as a repeated failure
indicates a defective condition that will not clear by replacing the fuse.
WARNING: Only qualified electrical personnel familiar with the construction and operation of
this equipment and the hazards involved should install, adjust, operate, or service this
equipment. Read and understand this manual and other applicable manuals in their entirety
before proceeding. Failure to observe this precaution could result in severe bodily injury or loss
of life.
60
20
10040 8020
0
10
100
90
80
70
60
50
40
30
Scans0
1
2 3 4 5 60 7
%Complete [ ]
Filter
Constant
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may
cause undesired operation.
Warning: Consult
user documentation.
Warning: Electrical
Shock Hazard.
__________________________________________________________________________________________________________________________________________________________________
6/20/2013 Page 3 of 4 ECN
No part of this publication may be reproduced without the prior agreement and written permission of Horner APG, Inc. Information in this document is subject to change without notice.
