IO-10MIXR-WE / IO-10MIXR-NWE SMART IO

® U.S. Registered Trademark

31-00427 | Rev.10-20

Honeywell Building Solutions

Honeywell

715 Peachtree Street NE

Atlanta, GA 30308

customer.honeywell.com

buildingcontrols.honeywell.com

GENERAL SAFETY

INFORMATION

• When performing any work (installation, mounting,

start-up), all manufacturer instructions and in

particular the Installation and Commissioning

Instructions (EN1B-0206IE10) are to be observed.

• The Smart IO and other related accessories, manual

disconnect modules, and the auxiliary terminal

packages) may be installed and mounted only by

authorized and trained personnel.

• Rules regarding electrostatic discharge should be

followed.

• If the Smart IO is modified in any way, except by the

manufacturer, all warranties concerning operation and

safety are invalidated.

• Make sure that the local standards and regulations are

observed at all times. Examples of such regulations are

VDE 0800 and VDE 0100 or EN 60204-1 for earth

grounding.

• Use only accessory equipment which comes from or

has been approved by Honeywell.

• It is recommended that devices be kept at room

temperature for at least 24 hours before applying

power. This is to allow any condensation resulting from

low shipping/storage temperatures to evaporate.

• The Smart IO must be installed in a manner (e.g., in a

lockable cabinet) ensuring that unauthorized persons

have no access to the terminals.

• Investigated according to United States Standard UL-

60730-1,UL-916, and UL60730-2-9.

• Investigated according to Canadian National

Standard(s) C22.2, No. 205-M1983 (CNL-listed).

• Do not open the Smart IO, as it contains no user-

serviceable parts inside!

• CE declarations according to LVD Directive

2014/35/EU and EMC Directive 2014/30/EU.

• Product standards are EN 60730-1 and EN 60730-2-9

for indoor use only.

Safety Information as per EN60730-1

The Smart IO is intended for residential, commercial, and

light-industrial environments.

The Smart IO is an independently mounted electronic

control system with fixed wiring.

The Smart IO is suitable for mounting in fuse boxes

conforming with standard DIN43880 and DIN19, and

having a slot height of max. 45 mm.

It is suitable for panel rail mounting on 35 mm standard

panel rail (both horizontal and vertical rail mounting

possible).

The Smart IO is used for the purpose of building HVAC

control and is suitable for use only in non-safety controls

for installation on or in appliances.

Table 13. Safety Information as per EN60730-1

Electric Shock

Protection

SELV

Pollution Degree Pollution Degree 2, suitable for use

in industrial environments.

Installation Safety class: Evaluated in final

product

Overvoltage
