IO-10MIXR-WE / IO-10MIXR-NWE SMART IO
7
31-00427 | Rev
.10-20
DIMENSIONS
57.5 mm
(2.26”)
130.7 mm
(5.15”)
105 mm
(4.13”)
45 mm
(1.77”)
1
10 mm
(4.33”)
1
...
...
5
6
7
8
