Specification

7-Day / Solar
Programmable Timer
FOR SECURITY, CONVENIENCE
AND ENERGY SAVINGS
67-6520 CB
March 2011
© 2011 Honeywell International Inc.
KEY FEATURES
• Forusewithincandescentandhalogenlights
upto500W.Requires40Wminimum.
• Largescreenwitheasy-to-readbacklitdisplay
• 7-dayprogramming(upto7onand7offtimesperweek)
andsunrise/sunsetactivation
• Randommodeturnslightson/offatrandom
foraddedsecuritywhenawayfromhome
• AutomaticDaylightSavings–noneedtoeverreprogram
• Simpletouse–easy3-buttoninterfaceforeasy
operationandprogramming
• Sleekdesignmountsflushwithwallplate
• Universalwiring(2-wireconnection)
• Singlepole(2-wire)ormulti-switch(3-way)installation
• Manualoverrideenablesloadtobeturnedon/off
withoutaffectingprogramming
• Programmingprotectedduringpoweroutages
• Canalsobeusedlikeaconventionalon/offswitch
* Does not include wallplate
RPLS540A1002 RPLS541A1001
SPECIFICATIONS
MODEL RPLS540A
Unit
Qty. 1
Dim. WxHxD (in.) 6.7 x 9.1 x 1.9
Carton Wt. (lbs.) 0.78
Cu. Ft 0.07
MODEL RPLS541A
Unit
Qty. 1
Dim. WxHxD (in.) 6.7 x 9.1 x 1.9
Carton Wt. (lbs.) 0.78
Cu. Ft 0.07
Retail Package
Qty. 5
Dim. WxHxD (in.) 8.7 x 14.6 x 9.8
Carton Wt. (lbs.) 3.91
Cu. Ft 0.72
DesignedinCanada.MadeinChina.
Automation and Control Solutions
Honeywell
1985DouglasDriveNorth
GoldenValley,MN55422-3992
800-468-1502
yourhome.honeywell.com
Not compatible
with
CFLs
OR
3-way
Single pole
RPLS540A RPLS541A
