COMPANY CONFIDENTIAL T77H332 User Manual Project Name Rev. FOXCONN Part No. Module Rev. NFC (Near Field Communication) Module 00 T77H332 00 Revision History Revision Date Originator Comment 0.0 2012/12/20 Wei.
COMPANY CONFIDENTIAL Content REVISION HISTORY ....................................................................................................................................................... 1 1. INTRODUCTION .......................................................................................................................................................... 3 2. WIFI ALLIANCE CONFORMANCE .............................................................................................................
COMPANY CONFIDENTIAL 1. Introduction The T77H332.XX IEEE802.11b/g/n module is based on Marvell 88W8782UB0-NAP2C000 solution that is provide the combined functions of DSSS and OFDM baseband modulation, MAC, CPU, OTP (one time programmable) memory, host interfaces, power management unit (PMU) and direct conversion WLAN RF radio. 1.1 Scope The wireless LAN is compliant to IEEE 802.11b and IEEE 802.11g and IEEE 802.11n standard. The data rate of 802.11b is up to 11Mbps and fallback rates of 5.5, 2, 1Mbps.
COMPANY CONFIDENTIAL 1.3 Electrical Characteristics Parameter Frequency Range Current Consumption Input Supply Voltage Absolute maximum voltage Minimum 2.4 - Typical ~ - Maximum 2.5 600 Units GHz mA 2.97 3.3 3.63 V 19.5 15.5 14.5 13.5 85 90 60 - dBm dBm dBm dBm ℃ % ℃ V V 11b 16.5 18 11g 12.5 14 Tx Output Power 11n-HT20 11.5 13 11n-HT40 10.5 12 Storage Temperature -20 ~ Storage Humidity 0 ~ Operation Temperature 0 ~ HBM 1.
COMPANY CONFIDENTIAL 1.4 USB 2.0 Characteristics Low / Full Speed Parameter Minimum Typical Maximum Units Input high voltage (driven) 2.0 - - V Input high voltage (floating) 2.7 - 3.6 V Input low voltage - - 0.8 V Differential input sensitivity 0.2 - - V Differential common mode range 0.8 - 2.5 V Output low voltage - - 0.3 V Output high voltage (driven) 2.8 - 3.6 V Output SE1 voltage 0.8 - Output signal crossover voltage 1.3 - 2.
COMPANY CONFIDENTIAL 2. WIFI ALLIANCE CONFORMANCE The Module is certified by the Wi-Fi Alliance. The Module and standard PC driver passes the Wi-Fi System Interoperability Test Plan including the following: A. IEEE 802.11-2007 Standard for LAN/MAN Specific requirements Part 11: Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) Specifications B. IEEE P802.
COMPANY CONFIDENTIAL 3. Hardware Specification 3.1 IEEE802.11b Mode Radio Technology Direct Sequence Spread Spectrum (DSSS) Operating Frequency 2412 ~ 2484MHz ISM band Modulation Schemes DQPSK, DBPSK and CCK Channel Numbers 11 channels for United States 13 channels for Europe Countries 14 channels for Japan Data Rate 1Mbps, 2Mbps, 5.5Mbps and 11Mbps Media Access Protocol (MAC) CSMA/CA (Carrier Sense Multiple Access with Collision Avoidance) Transmitter Output Power 18.0 dBm+/-1.
COMPANY CONFIDENTIAL Sensitivity Level Typical –87dBm for 18Mbps @ 10% PER Typical –75dBm for 54Mbps @ 10% PER EVM Typical –31dB for 6Mbps @15dBm output power Typical –31dB for 54Mbps @15dBm output power 3.3 IEEE802.11n (HT20) Mode Radio Technology Orthogonal Frequency Division Multiplexing (OFDM) Operating Frequency 2412 ~ 2472MHz ISM band Modulation Schemes BPSK, QPSK, 16QAM, 64QAM Channel Numbers 11 channels for United States 13 channels for Europe Countries Data Rate 800ns GI: 6.
COMPANY CONFIDENTIAL Frequency Accuracy +/-15ppm Minimum Receiver Sensitivity Level Typical –88dBm for 13.5Mbps @ 10% PER Typical –79dBm for 54Mbps @ 10% PER Typical –69dBm for 135Mbps @ 10% PER Typical –31dB for MCS0 @15dBm output power EVM (Test condition: Typical –31dB for MCS7 @15dBm output power Enable full packet channel estimate) Remark: The minimum sensitivity level is measured in FOXCONN RD Lab in shielding room.
COMPANY CONFIDENTIAL 3.7 Return Loss Measurement for S11 Return Loss Measurement for S11 -20.536dB@2412MHz Main antenna -27.920dB@2442MHz -38.556dB@2484MHz -17.771dB@2412MHz Aux antenna -26.397dB@2442MHz -19.879dB@2484MHz Main antenna Aux antenna Remark: the return loss measurement is base on air without any materials.
COMPANY CONFIDENTIAL 3.8 Radiated Emission Remark: we will provide the official regulatory test report from 3rd party lab. 4. Product Requirements 4.1 Hardware Requirements Form factor Host Interface PCB Antenna connector 40 mm x40mm module with 8-pin B.T.B connector USB2.0 interface 4-layer design RF switch connector 4.2 Hardware Architecture The T77H332.XX IEEE802.
Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence.
installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains IC: 2878DT77H332”. Plaque signalétique du produit final Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où l'antenne peut être installée de telle sorte qu'une distance de 20cm peut être maintenue entre l'antenne et les utilisateurs.
Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna.
equipment and services; Part 1: Common technical requirements EN 301 489‐17 V2.1.1 2009 Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz high performance RLAN equipment National Authorities were informed according to Article 6.4 of Frequency Notification. Special Requirements are considered. The product is labeled with CE Marking.
fid-Dirrettiva 1999/5/EC. Magyar [Hungarian] Polski [Polish] Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. Niniejszym [nazwa producenta] oświadcza, że [nazwa wyrobu] jest zgodny z zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC.
