User's Manual

Confidential

1. Introduction

Project Name: 802.11n (5G) 2x2 MIMO WIFI module

This documentation describes the product specification of the WIFI 802.11n

module, it is a confidential document of FOXCONN.

1.1 Scope

The MIC-B2 802.11n module provides wireless modem functionality

utilizing OFDM technology. The objective of this use manual is to verify the

functionality of the MIC-B2 802.11n module RF/Digital electronic design

against the design specifications.

This device is operated in 5180~5240MHz (indoor only) and

5745~5825MHz.

1.2 Function

 Support IEEE 802.11n 2x2 MIMO specified functions

 SDIO V2.0 interface support
