Installation Guide

HON HAI PRECISION IND. CO., LTD. HSINCHU SCIENCE PARK BRANCH OFFICE
Introduction
O3 WIFI Module is compliance with IEEE802.11,IEEE 802.11b and IEEE 802.11g Standards.
1.1 WLAN Features
Operating Frequency 2400 ~ 2483.5 MHz ISM band
Modulation Schemes 802.11: DPSK, DBPSK
802.11g: OFDM, DQPSK, DBPSK and CCK
802.11b: DQPSK, DBPSK and CCK
Channel Numbers IEEE 802.11 compliant:
1 ~ 13 channels for United States, Europe and Japan
IEEE 802.11b/g compliant:
1 ~ 11 channels for United States
1 ~ 13 channels for Europe, Japan
WLAN Data Rate 802.11g: Up to 54 Mbps with auto fallback to 48, 36, 24, 18, 12,
9 and 6 Mbps.
802.11b: Up to 11 Mbps with auto fallback to 5.5, 2 and 1Mbps.
802.11 legacy: Up to 1Mbps and 2Mbps
Media Access Protocol CSMA/CA with ACK
Transmitter Output Power
Item
Condition
Min
Typ.
Max
Unit
Transmit
power level
802.11 legacy
1Mbps
-1.5
0
1
dBm
2Mbps
-1.5
0
1
dBm
802.11g
6Mbps
3.5
5
6
dBm
9Mbps
3.5
5
6
dBm
12Mbps
3.5
5
6
dBm
18Mbps
3.5
5
6
dBm
24Mbps
3.5
5
6
dBm
36Mbps
2.5
4
5
dBm
48Mbps
2.5
4
5
dBm
