User's Manual

2 Product Overview

This documentation outlines the QCA9375 WiFi Module. It is 802.11a/b/g/n compatible, ARIB STD-T66

Compatible; the module Host I/F is USB 2.0.

IEEE 802.11 a/b/g and 802.11n payload data rates for Wireless Local Area Network (WLAN).

1.1 Operating Frequency: 2402~2483.5MHz, 5150MHz~5250MHz, 5250MHz~5350MHz,

5470MHz~5725MHz, 5725MHz~5845MHz

1.2 Modulation: DBPSK, DQPSK, CCK, BPSK, QPSK, 16QAM, 64QAM

1.3 Data Rates: 1/2/5.5/11Mbps (11b)

6/9/12/18/24/36/48/54 Mbps (11g)

MCS0~MCS15

1.4 Security: it supports WEP, TKIP, AES, WPA/WPA2 and WAPI

1.5 Full 802.11e QoS support including WMM.

1.6 Support Short Guard interval and Frame aggregation with A-MPDU

The module is designed with a WTB (Wire to Board) connector to connect to host. Dimension is 40.0mm

x37.5mm x 5.45mm (typical).

Below figure1 shows functional block diagram of the WLAN module.

Figure 1: Module Functional Block Diagram
