4.5.5 WLAN RF Specification- 802.11n (5GHz) HT20
g: 5180MHz~5240MHz, MCS0~MCS5 target power reduced to 12dBm for FCC power density limit.
h: 5700MHz, MCS0~MCS4 target power reduced to 12.5dBm for FCC bandedge limit.
i: 5180MHz, MCS0~MCS5 target power reduced to 12.5dBm for TELEC adjacent channel power limit
Items Contents
Specification IEEE 802.11a/n HT20
Mode OFDM
Channel
5150MHz~5250MHz, 5250MHz~5350MHz,
5470MHz~5725MHz, 5725MHz~5845MHz
Data rate (MCS index) MCS0/1/2/3/4/5/6/7
TX Characteristics
Min. Typ. Max. Unit
1. Power Levels (per chain)
1) Target Power@MCS0
12 13.5
g,h,i
15 dBm
2) Target Power@ MCS1
12
13.5
g,h,i
15 dBm
3) Target Power@ MCS2
12
13.5
g,h,i
15 dBm
4) Target Power@ MCS3
12
13.5
g,h,i
15 dBm
5) Target Power@ MCS4
12
13.5
g,h,i
15 dBm
6) Target Power@ MCS5
11 12.5
g,i
14 dBm
7) Target Power@ MCS6
10 11.5 13 dBm
8) Target Power@ MCS7
9 10.5 12 dBm
2. Spectrum Mask @ Target Power
1) at fc +/- 11MHz
- - -20 dBr
2) at fc +/- 20MHz
- - -28 dBr
3) at fc > +/-30MHz
- - -45 dBr
3. Modulation Accuracy(EVM)@ Target Power
1) MCS0
- - -5 dB
2) MCS1
- - -10 dB
3) MCS2
- - -13 dB
4) MCS3
- - -16 dB
5) MCS4
- - -19 dB
6) MCS5
- - -22 dB
7) MCS6
- - -25 dB
8) MCS7
- - -27 dB
4. Frequency Error
-10 - +10 ppm
5. Tx spurious emission - - -54 dBm
RX Characteristics
Min. Typ. Max. Unit
6. Minimum Input Level Sensitivity
1) MCS0 (PER < 10%) -
-88 -83
dBm
2) MCS1 (PER < 10%) -
-86 -81
dBm
3) MCS2 (PER < 10%) -
-84 -79
dBm
4) MCS3 (PER < 10%) -
-80 -76
dBm
5) MCS4 (PER < 10%) -
-77 -73
dBm
6) MCS5 (PER < 10%) -
-74 -69
dBm
7) MCS6 (PER < 10%) -
-72 -67
dBm
8) MCS7 (PER < 10%) -
-71 -66
dBm
7. Maximum Input Level (PER < 10%)
-30 -
- dBm
8. Rx spurious emission - - -58 dBm
