Start-up
5.2.2 Surface-mounting box installation
To install the switch actuator and meter in a surface-
mounting box, please proceed as follows:
• Switch o the fuse of the power circuit.
• Connect the actuator to L (D) and N (C) to obtain
power supply (see fig. 2).
• Route the switched phase (B) to the consumer
(see fig. 2).
• Fix the actuator to an appropriate surface-
mounting box (e.g. Abox 025 or Abox 040) (see
figure 3).
• Fix the actuator to the holding mandrel using the
fixing lug.
• Close the surface-mounting box using the cor-
responding cover.
• Switch the fuse of the power circuit on again, to
activate the teach-in mode of the device (see „5.3
Teaching-in“ on page 36).
5.3 Teaching-in
Please read this entire section before starting
the teach-in procedure.
First set up your Homematic IP Access Point via
the Homematic IP app to enable operation of
other Homematic IP devices within your system.
For further information, please refer to the oper-
ating manual of the Access Point.
