General system information
Device overview (see figure 1):
(A)
Fixing lug
(B)
Connecting terminal 1
(switched phase)
(C) Connecting terminal N (neutral conductor)
(D) Connecting terminal
L (phase conductor)
4 General system information
This device is part of a smart home system and works
with the Homematic IP radio protocol. All devices of the
system can be configured comfortably and individually
with a smartphone or PC. The available functions
provided by the system in combination with other
components are described in the Homematic IP User
Guide. All current technical documents and updates are
provided at www.eQ-3.de.
