Installation Guide

34 35
PARTS LIST
HOMEPLOW
Electric Lift
Parts indented are included in the assembly under which they are indented.
ITEM PART NO. QTY. DESCRIPTION
23200/23250 HomePlow ELectric Lift
1 13994 1 • LiftFrameAssembly 
 2 13997 1 • LiftArm  
 3 13998 1 • A-Frame
 4 13988 1 • PivotBar
 5 09456 1 • MoldboardAssemblyRight
 6 13951 1 • MoldboardAssemblyLeft 
 7 09449YEL 1 • CuttingEdgeMiddle
 8 09450YEL 2 • CuttingEdgeOuter
  08386 1 • PowerLiftCarton  
 9 13286 4 ••TripSpring
 10 22887 1 ••ElectricLIft  
 11 22888 1 ••ElectricLiftHarness
  22893 1 ••RemoteControlKit
 12 22891 1 •••RemoteController
 13 22894 1 •••RemoteControlReceiver
 14 09917 1 ••PlowMarkerKit
 15 13969 1 ••SpacerPlate
 16 13984 2 ••CompressionSpring
 17 13986 2 ••SpringArm
 18 13987 2 ••SpringArmCover
 19 13985 2 ••PivotArm
 20 14008 2 ••SpacerTube
 21 21542 1 ••Chain5/16x20”
  08955 1 ••HardwareBag
 22 22851 4 •••Eyebolt3/8-16x4”
 23 20526 4 •••FinishNut3/8-16
 24 20305 5 •••Locknut3/8-16
 25 20094 5 •••BoltH1/2-13x1-1/4”Gr.5
 26 20307 14 •••Locknut1/2-13
 27 21943 8 •••BoltC1/2-13x1-3/4”Gr.5
 28 22850 2 •••ClevisPin1/2x1-1/4”
 29 22845 5 •••HairPinCotter1/8”
 30 20147 1 •••BoltH5/8-11x3-1/2”Gr.5
 31 20309 1 •••Locknut5/8-11
 32 11101 2 •••HingePin
 33 22436 2 •••Pin1x3”
 34 20420 2 •••CotterPin1/4x2”
 35 22083 1 •••LynchPin  
 36 20102 1 •••BoltH1/2-13x3-1/4”Gr.5
 37 22816 3 •••PivotPin1/2x3”
 38 20355 3 •••Flatwasher1/2”
 39 20003 2 •••BoltH1/4-20x3/4”Gr.2
 40 20303 2 •••Locknut1/4-20
 41 20068 1 •••BoltH3/8-16x2-1/2”Gr.5
34
