Installation Guide

28 29
(Fig. 37)
(Fig. 38)
REMOVE PLOW
FROM VEHICLE
➊Push here to put slack in chain
➋ Disconnect electric plug (Models 23200/23250 only)
➌ Remove pin
➍ Lift here and pull away from vehicle
➎ Replace pin to plow hitch
➊
➋
➌
➍
(Fig. 40)
(Fig. 41)
(Fig. 42)
(Fig. 43)
➎
7
SAFETY PRECAUTIONS - See pages 2-3 for denitions
28
Lower plow all the way down.
Disconnect electrical plug (Models
23200/23250 only) (g. 41)
and install weather covers to both
end of the harness. Remove Hitch pin
(g. 40). Gently lift at lift frame decal
(g. 42) and slide lift frame out of
receiver hitch on vehicle (g. 43).
Re-install Hitch pin thru Lift Frame.
