Installation Guide
26 27
ATTACH PLOW
TO VEHICLE
Remove Hitch Pin. Align the vehicle
receiver hitch so that the male tube on
the lift frame is lined up directly in front
of the receiver hitch (g. 30). Lift slightly
on the Lift Frame decal (g. 31) and push
plow assembly into the vehicle receiver
hitch until the pin holes align (g. 32).
Proper install is shown in Figure 34.
Connect electrical plug (Models
23200/23250 only)(g. 33).
➊Remove pin
➋ Lift here and push toward vehicle
➌ Re-install pin
➍ Connect electrical plug
(Models 23200/23250 only)
➊
➋
➋
➌
➍
(Fig. 31)
(Fig. 30)
(Fig. 32)
(Fig. 33)
(Fig. 34)
2
30
7, 9
SAFETY PRECAUTIONS -
See pages 2-3 for denitions
