Installation Guide
24 25 24
Remove PinLift here and push toward vehicle.
Lift Frame
STEP 3a
Align vehicle so that the male tube on the lift frame is lined up directly in front
of the receiver hitch (g. 21). Lift slightly on the Lift Frame decal (g. 22) and
push plow assembly into the vehicle receiver hitch until the pin holes align (g. 23).
Proper install is shown in Figure 24.
(Fig. 21)
(Fig. 23)
(Fig. 24)
STEP 3: INSTALL PLOW ONTO VEHICLE
(Fig. 22)
2
9
SAFETY PRECAUTIONS -
See pages 2-3 for denitions
WIRING INSTALLATION – Electric Lift (cont.)
