Unit Numbers
OmniPro II systems have 511 total Unit Numbers. They consist of HLC, UPB, CentraLite, RadioRA, ALC, Compose, and X-10
module unit numbers, hardwire voltage output unit numbers, and internal flag unit numbers as follows:
OmniPro II Unit Numbers Module / Output Unit Numbers
1 - 16
HLC Room 1 and 2, UPB Unit ID 1-16, CentraLite loads 1-16, RadioRA Lighting Zones or
Master Controls 1-16, and X-10 modules 1 – 16 (House Code X)
17 - 32
HLC Room 3 and 4, UPB Unit ID 17-32, CentraLite loads 17-32, RadioRA Lighting Zones
and Master Controls 17-32, or X-10 modules 1 – 16 (House Code X+1)
(1 - 31) ALC addresses 1-31, Module 1 - Branch 1 *
33 - 48 HLC Room 5 and 6, UPB Unit ID 33-48, CentraLite loads 33-48, RadioRA Lighting Zones
and Master Controls 33-48, or X-10 modules 1 – 16 (House Code X+2)
49 - 64 HLC Room 7 and 8, UPB Unit ID 49-64, CentraLite loads 49-64, RadioRA Lighting Zones
and Master Controls 49-64, or X-10 modules 1 – 16 (House Code X+3)
(33 - 63) ALC addresses 1-31, Module 1 - Branch 2 *
65 - 80 HLC Room 9 and 10, UPB Unit ID 65-80, CentraLite loads 65-80, or X-10 modules
1 – 16 (House Code X+4)
81 - 96 HLC Room 11 and 12, UPB Unit ID 81-96, CentraLite loads 81-96, or X-10 modules
1 – 16 (House Code X+5)
(65 - 95) ALC addresses 1-31, Module 1 - Branch 3 *
97 - 112 HLC Room 13 and 14, UPB Unit ID 97-112, CentraLite loads 97-112, or X-10 modules
1 – 16 (House Code X+6)
113 - 128 HLC Room 15 and 16, UPB Unit ID 113-128, CentraLite loads 113-128, or X-10 modules
1 – 16 (House Code X+7)
(97 - 127) ALC addresses 1-31, Module 1 - Branch 4 *
129 - 144 HLC Room 17 and 18, UPB Unit ID 129-144, CentraLite loads 129-144, or X-10 modules
1 – 16 (House Code X+8)
145 - 160 HLC Room 19 and 20, UPB Unit ID 145-160, CentraLite loads 145-160, or X-10 modules
1 – 16 (House Code X+9)
(129 - 159) ALC addresses 1-31, Module 2 - Branch 1 *
161 - 176 HLC Room 21 and 22, UPB Unit ID 161-176, CentraLite loads 161-176, or X-10 modules
1 – 16 (House Code X+10)
177 - 192 HLC Room 23 and 24, UPB Unit ID 177-192, CentraLite loads 177-192, or X-10 modules
1 – 16 (House Code X+11)
(161 - 191) ALC addresses 1-31, Module 2 - Branch 2 *
193 - 208 HLC Room 25 and 26, UPB Unit ID 193-208, or X-10 modules 1 – 16 (House Code X+12)
209 - 224 HLC Room 27 and 28, UPB Unit ID 209-224, or X-10 modules 1 – 16 (House Code X+13)
(191 - 223) ALC addresses 1-31, Module 2 - Branch 3 *
225 - 240 HLC Room 29 and 30, UPB Unit ID 225-240, or X-10 modules 1 – 16 (House Code X+14)
241 - 256 HLC Room 31, UPB Unit ID 241-250, or X-10 modules 1 – 16 (House Code X+15)
(225 - 255) ALC addresses 1-31, Module 2 - Branch 3 *
257 – 272 Outputs 1-16, 1st Expansion Enclosure *
273 – 288 Outputs 1-16, 2nd Expansion Enclosure *
289 – 304 Outputs 1-16, 3rd Expansion Enclosure *
305 – 320 Outputs 1-16, 4th Expansion Enclosure *
321 - 336 Outputs 1-16, 5th Expansion Enclosure *
337 – 352 Outputs 1-16, 6th Expansion Enclosure *
353 - 368 Outputs 1-16, 7th Expansion Enclosure *
369 - 384 Outputs 1-16, 8th Expansion Enclosure *
385 - 392 Voltage Outputs (1-8), Fully Configurable
393 – 511 Internal Flags
“X” Represents the House Code setting on the OmniPro II Controller
“*” Internal Flags
Page 20
