Manual

Purpose

KKmulticopter Flash Tool is a tool that will easily upload selected rmware to your

KKmulticopter board, ATmega8 based ESC or Smart LCD pro. It is designed to support users

that never have ashed rmware to a micro-controller board. All that is needed is for the

user to select the programmer you're using to ash the board, select board or controller

type, and desired rmware version. You will then have the ability to ash a rmware le

from your PC or directly from the Internet by selecting from a list of latest available

rmware versions. This repository is maintained by me, so if I miss a new version please

contact me.

Also, this the tool can be used to save some of the possible settings you normally do by

using the pots within the PC. (old KK boards only)

The tool will save the settings upon exiting the KKmulticopter Flash Tool. You will not need

to set everything back up upon re-launching the KKMulticopter Flash Tool. This is because

the KKMulticopter Flash Tool saves the settings you selected upon sucessfully ashing your

controller board.

To get more informations on how to ash BL-ESC see also the KKMulticopter Flashtool

manual.

The tool can also create a USB linker from an Arduino, which cn be used to ash bootloader

enabled ESC. How to make a Arduino USB linker.

General requirements

To run the tool you need a normal Windows PC, Mac or Linux PC. When using your

computer it is required to have the latest version of Java installed (at least in version 6). You

have to be careful when you download it, because the Oracle homepage oers you

automatically a download according to the version of the browser that you use. So if you

have a 64 bit OS () you should also use a 64 bit browser to download Java. Firefox and

Chrome are no 64 bit browsers, but IE () 8 and IE9 are 64 bit.

An ISP programmer with correct installed driver.

Summary of content (6 pages)

PAGE 1
8/6/2016 Manual [lazyzero.de] YOU ARE HERE /  / EN / MODELLBAU / KKMULTICOPTER FLASHTOOL / MANUAL en:modellbau:kkmulticopter ashtool:manual Manual Purpose KKmulticopter Flash Tool is a tool that will easily upload selected ᴀ㔄rmware to your KKmulticopter board, ATmega8 based ESC or Smart LCD pro. It is designed to support users that never have ᴀ㔄ashed ᴀ㔄rmware to a micro-controller board.
PAGE 2
8/6/2016 Manual [lazyzero.de] An Internet connection is required if you want to use the repository. Upon launching the KKMulticoper Flash Toll the descriptive ᴀ㔄le of the repository with all informations will be downloaded. Installation On Windows or Linux You just have to un-zip the archive you downloaded to any folder you like. Mac OS X Just open the dmg-image and move the kkMulticopter Flash Tool to the Applications folder.
PAGE 3
8/6/2016 Manual [lazyzero.de] 2. you can cache Ḝrmware to your local hard drive. This downloads the ᴀ㔄rmware you don't already have on your hard drive. You can ᴀ㔄lter conᴀ㔄gure the download by checking the ᴀ㔄rmware types you are interested in obtaining. 3. you can set the user language. Contribute In this menu you can send me a bug report or commit Ḝrmware you found on the Internet or you wrote to be added to the repository.
PAGE 4
8/6/2016 Manual [lazyzero.de] 1. Select your ISP programmer. 2. This is the port your programmer uses. A lot of programmers have a USB plug, but they are serial programmers. In this case select the correct serial port. Only avrisp mkII, USBasp and USBtiny are real USB programmers. 3. For serial programmers you can change the default baud rate. Therefore you have to enable the checkbox and change the value of the baud rate ᴀ㔄eld.
PAGE 5
8/6/2016 Manual [lazyzero.de] 13. This area will print status messages. If you have problems ᴀ㔄ashing your board, you can send me a dump of the content of this area. Preparing the hardware  Remove all ESC from the KK board! They may draw to much current from the USB port, that will cause in a shutdown of the port or the programmer. Depending on when it happens during the Ḵashing you may brick your board. Flash a rmware Flashing new ᴀ㔄rmware is very easy.
PAGE 6
8/6/2016 Manual [lazyzero.de] For the ᴀ㔄rmware variants that are developed by kapteinKuk (KK), Mike Barton (XX), David alias HappySundays (NeXtcopterPlus, OpenAero) or Minsoo Kim(XX_KR). Are more or less completely available by the repository. Big advantage of the repository is that you don't have to search the Internet to obtain an older ᴀ㔄rmware versions. Also, I'll try to keep the repository as up-to-date as possible. If I miss a new version you can contact me by the Contact form on the download page.
