User Manual

D9257

92579257

9257

instruction

instructioninstruction

instruction

Specs

SpecsSpecs

Specs：

：：

：

Dead band: 0.002ms(Default)

Control System: +Pulse Width Control

Working frequence: 1520µs / 80hz Digital

mode/Analogy mode

(RX) Required Pulse: 3.0 ~ 5.0 Volt Peak to Peak Square

Wave

Operating Voltage: 4.8 ~ 6.0 V DC Volts

Operating Temperature Range: -10 to + 60 Degree C

Operating Speed (4.8V): 0.08 sec/60° degrees at no load

Operating Speed (6.0V): 0.07 sec/60° degrees at no load

PAGE 1
D9257 instruction Specs： Specs： ◆ Speed: peed:0.08S/4.8V 0.07S/6V ◆ Torque: Torque:3.8KG/4.8V 4.2KG/6V Dead band: 0.002ms(Default) Control System: +Pulse Width Control Working frequence: 1520µs / 80hz Digital mode/Analogy mode (RX) Required Pulse: 3.0 ~ 5.0 Volt Peak to Peak Square Wave Operating Voltage: 4.8 ~ 6.0 V DC Volts Operating Temperature Range: -10 to + 60 Degree C Operating Speed (4.8V): 0.08 sec/60° degrees at no load Operating Speed (6.0V): 0.
PAGE 2
Stall Torque (4.8V): 3.8 kg.cm Stall Torque (6.0V): 4.2 kg.cm 360° Modifiable: NO Motor Type: Coreless Motor Potentiometer Drive: Indirect Drive Driver Type: FET Bearing Type: Dual Ball Bearings Gear Type: Plastic gear Programmable: YES Connector Wire Length: 18.0 cm Dimensions: 36x15.3x21.
