Operation Manual

Exterior Structure
05-6
Removing the ventilation grate
• Push the lock(s)
l
up as far as they will go or turn the
lock(s)
m
to the right (for Thetford: push both locks
towards the centre).
• Carefully lift open the ventilation grid on the left-hand side
(Thetford: lift up).
• Then pull the right-hand side out of the bracket (Thetford:
press the lower edges down out of the bracket).
1
We recommend that you remove the ventilation grate if
the outside temperature is very high. This allows more air
to permeate to the refrigerator, intensifying refrigeration.
The ventilation grids must remain rmly mounted while
driving or when it is raining.
Heating
The heating system is supplied with fresh air from outside
j
.
This ventilation ap also permits exhaust air from the system
to escape.
Blocked ventilation openings can lead to suffocation!
Therefore, never block ventilation openings. When
operating in winter ensure that the chimney outlet is not
blocked.
