1. Make sure the power supply coincide with the source of your instrument and be adequately grounded before you plugged into electricity.
2.open the lid of the instrument,take out the inner cylinder,then you will see electric heating tube.
3. Diverter switch to the position of Exhaust steam on the bottom of the left surface (discharge the cold air out of the sterilizer in the process of
temperature rise), turn on a switch of the instrument, power indicator will be on and you can set the temperature of displacement,the
temperature of sterilization,the time of sterilization,after finish setting these things,please press the run button to start,then you will hear the
buzzer warning and see the water indicater on,it is a signal that remind the operator should add water now because of water
shortage.(Notes:it is better add tapwater,not purified water or distilled water.)
4. Use a plastic tube to connect the water tap to the heating tube(or remove the round covering in the bottom of the inside cylinder and connect
the plastic tube), turn on the tap to add the water gradually until the water indicator is on,and it is in the Temperature - rise period.
5.Fit the inner tub to the instrument, put the wrapped goods ready for sterilization in sequence into the inner tub(the
suitable volume is 200mm×200mm×100mm),make sure that there is still some space left inside of the tub in order to let
the steam penetrate well into the goods and increase the effect of sterilization.also please take care that the security
valve, exhaust valve and the steam hole in the pressure control switch not be plugged during the process,at last,fasten the
lid.(notes: if the locking way is by securing rod,then please tightened it in diagonal form)
6. when the instrument is in the period of temperature-rise, temperature-rise indicator will be on,and you can hear the buzzer warning as soon
as the temperature reaches the required temperature of displacement, it is a signal that remind the operator should switch off the Exhaust
steam/discharging water knob on the bottom of the left surface. (If the customer have the high requirement on the uniform temperature in
different parts of the inner cylinder,then you can switch the Exhaust steam/discharging water knob towards the leftside a little bit of time to
discharge the small amount of steam continuously to ensure the uniform temperature inside. )when the working temperature reaches the
designed temperature,the instrument is in the process of sterilization,then the machine will count down to the end of sterilization.
7.Please turn off the power as soon as the sterilization finishes, Diverter switch to the position of Exhaust steam on the bottom of the left
surface to relief the pressure,it is not allowed to take out the sterilized goods from the instrument until the pressure gage reaches 0.
8. This self-control type have the self - protection device, ,it will switch off the heating power automatically when exceeding the temperature
limits,and also the instrument can also switch off the heating power automatically and the user can get a warning light as soon as the water
bellows the designed water level.
9. parameters functions and setting
Parameter
content
Functions and explanation
P——1
the temperature of displacement: usually
around 102
℃
when the working temperature reaches the designed temperature
of displacement,it reminds the user to switch off Exhaust steam on
the bottom of the left surface
P——2
the temperature of sterilization: RT+5 ～
134℃
The suitable temperature for user is 121℃、126℃
P——3
time of sterilization: 0～9999minutes
The suitable time of sterilization should be within 45
minutes.
P——4
Time of drying:0 minutes
The suitable time of drying should be within 45minutes,it
is an optional parameter
P——5
Heating proportional control: 10～10
Please don’t adjust this parameter by yourself
Notes: when you want to set these parameters,first press the setting key,it will display P——1 on the temperature measuring screen(on the top
side) and display the value of the parameter on the bottom side of the screen,then you are free to use the “+” key or “-” key to adjust the
parameter,press the setting key again to switch automatically to the next parameter,it will return to the normal automatically on the screen when you
press the setting key for 5 times.
Ⅷ、
Points for attention
1. The shell of the instrument must be adequately grounded and always checked to avoid accidents.
2. The instrument must be kept in an place which is airy and dry and no inflammables & explosives.
