User's Manual

6
Register each COMMUNICATOR
®
as follows:
Note: Communicators must be within 6 feet (1.83 meters) of the base station while
being registered.
 Be certain all Communicators to be registered are turned off and the base station is
plugged in and its power is on. Other Communicators can be on or off. See Figure 30
for base station power adapter/supply connections to the J29 connector.
 Open the base station and locate the items shown in Figure 5.
If no Communicators are on, the status light will begin blinking red. If any
Communicators are on, the status light will be on steady green.
Press and release the START REGISTRATION button.
The Communicator ID display will show a small “o” for open, and the status light
will blink green.
 Press and hold the B button on the Communicator while pressing and releasing its
PWR (power) button to turn the Communicator on, and release the B button. This
will cause the Communicator to enter the registration mode.
The status light in the base station will be blinking green and the Communicator
ID display will continue to show a small “o” for open.
The power lights next to the A1 and A2 buttons on the Communicator will be
blinking red then will change to green.
When the registration is successfully completed:
 The green status light in the base station will be on steady and the Communicator
ID display will show the ID number assigned to this Communicator. ID numbers
are assigned sequentially as 0 thru 9, A, b, C, d and E.
 One of the power lights on the Communicator will remain on steady green.
If the registration failed:
 A message in the headset will say “Beltpac/Headset #, Battery Low/Half/Full,
Registration …” The Communicator power light/s will blink red and after a delay of
up to 1.5 minutes you will hear “Registration failed.”
 Note the condition of the STATUS light in the base station. Press the RESET button.
The STATUS light may blink and change colors. When the STATUS light returns to
its previous condition, press the START REGISTRATION button and repeat the
registration procedure.
If the registration fails again:
In the USA, call HME Customer Support at 1-800-848-4468.
Outside the USA, call your local HME representative for assistance.
Figure 5. Registration buttons and indicators
Communicator ID display
Status light
RESET button
CLEAR ALL REGISTRATION button
REGISTRATION button
