Safety Timer
Press the ✚ button once to advance to the “
Safety
Timer“ screen. This screen will allow you to set the maximum charge time in
order to prevent accidental overcharging.
Capacity Cut-o
Press the ✚ button once to advance to the “
Capacity
Cut-off“ screen. This screen will allow you to set the maximum charge capac-
ity in order to prevent accidental overcharging.
Key Beep & Buzzer
Press the ✚ button once to advance to the “
Key Beep
Buzzer
“ screen. This screen will allow you to control the sound options on the
X1.
Input Power Cut-o
Press the ✚ button once to advance to the “
Input
Power Cut-off“ screen. This screen will allow you to set the minimum input
voltage cut-o in order to protect the input source.
The X1 recognizes the cell count of the Lithium battery automatically at the be-
ginning of the charge or discharge process to avoid an erroneous setting by the
user. In the case of a highly discharged battery, the X1 may initially misread the
cell count. By setting the Battery Check Timer, the user can delay the voltage er-
ror message, allowing the X1 enough time to determine the correct cell count.
Normally, 10 minutes is enough time to perceive the cell count correctly. For a
battery of larger capacity, you may extend the time term. However, if you set it
too long for a battery of smaller capacity, the charge or discharge process can
be  nished within the time term with an erroneous cell count. This can cause a
fatal result. If the processor recognizes the cell count incorrectly at the begin-
ning of the charge or discharge process, you may extend the time. Otherwise,
you should use the default value.
See pg. 28 for instructions on accessing the “
CHK Time“
screen.
Overview (cont.)
Battery Check Timer
LithiumAdditional Features & Settings
Safety Timer
ON 120min
Capacity Cut-off
ON 5000mAH
Key Beep ON
Buzzer ON
Input Power Low
Cut-off 10.0V
LiPo/LiIo/LiFe
CHK Time 10min
