Lithium
Additional Features & Settings
Press the ■ button repeatedly until you reach the
“
USER SET PROGRAM->“ screen.
Battery Type
Press the ► button once to advance to the “
V.Type“
screen. This screen will allow you to choose the type of lithium battery you wish
to charge. Instructions for setting the battery type can be found on pg. 13.
Each time you press the ✚ button you will advance to the next setting.
Pressing the
▬
button will take you back to the previous selection.
Battery Check Timer
Press the ✚ button once to advance to the “
CHK Time“
screen. This screen will allow you to delay the voltage error message in the case
of a highly discharged battery.
NiMH Sensitivity
Press the ✚ button once to advance to the “
NiMH Sen-
sitvity“ screen. This screen will allow you to adjust the cuto voltage of the
automatic charge termination of NiMH batteries.
NiCd Sensitivity
Press the ✚ button once to advance to the “
NiCD Sen-
sitvity“ screen. This screen will allow you to adjust the cuto voltage of the
automatic charge termination of NiCD batteries.
USB Temperatre Cut-o
Press the ✚ button once to advance to the “
Temp Cut-
off“ screen. This screen will allow you set the battery temperature at which the
charging process will be terminated. This feature requires an optional tempera-
ture probe that is not supplied with the X1.
Waste Time
Press the ✚ button once to advance to the “
Waste
Time“ screen. This screen will allow you set the time delay between
charge>discharge cycles, allowing time for the battery to cool.
Overview
USER SET
PROGRAM->
LiPo
V.Type 3.7V
LiPo/LiIo/LiFe
CHK Time 10min
NiMH Sensitivity
D.Peak Default
NiCd Sensitivity
D.Peak Default
USB/Temp Select
Temp Cut-off 80C
Waste Time
CHG>DCHG 1min
