Manual
22
BEFORE YOU BEGIN DISCHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SEFETY
INFORMATION CONTAINED ON PAGES 47.
After selecting the correct battery type (see pg 21), use the ✚ or
▬
buttons to
select to the “DISCHARGE“ mode.
Press the ► button and the amp rate value will begin
ashing. Use the ✚ or
▬
buttons to adjust the value
to the desired rate. Follow the instructions provided with your battery when
setting the amp rate.
Press the ► button again and the voltage cuto will
begin to ash. Use the ✚ or
▬
buttons to adjust the
value to the desired rate. Follow the instructions provided with your battery
when setting the voltage cuto . The X1 will stop discharging when the battery
has reached the preset voltage cuto .
Press and hold the ► button to begin discharging.
Once discharging has commenced, the charger will
display the following real-time information: Battery type, discharging current,
battery voltage, discharging time and discharged capactiy.
When discharging is complete the X1 will chime.
Press and hold the ► button to begin charging.
Once charging has commenced, the charger will dis-
play the following real-time information: Battery type,
charging current, battery voltage, charging time and charged capactiy.
Once the battery is fully charged the screen will read “
FULL” and the charger
will emit a chiming sound. Press the ■ button to stop charging. You may press
the ■ button at any time during the charging process to stop charging.
NiCd/NiMH Charge Mode (cont.)
NiCd/NiMH Discharge Mode
LithiumNiCd/NiMH
NiMH 1.4A 5.98V
CHG 022:43 00384
NiMH 1.4A 5.98V
CHG 022:43 00384
NiMH DISCHARGE
0.1A 0.1V
NiMH DISCHARGE
0.1A 0.1V
Warning
