Once charging has commenced, the charger will display
the following real-time information: Battery type/cell
count, charging current, battery voltage, charging time and charged capactiy.
DURING CHARGING, THE BATTERY SHOULD BE PLACED INSIDE A
FIRE PROOF/RETARDANT BAG AND ON A FIRE PROOF SURFACE, AWAY
FROM OTHER COMBUSTIBLE OBJECTS.
If you are using a balance adapter, you may press the ✚
button to view the voltage of each individual cell.
Once the battery is fully charged the screen will read “
FULL” and the charger
will emit a chiming sound. Press the ■ button to stop charging. You may press
the ■ button at any time during the charging process to stop charging.
Lithium Fast Charge Mode (cont.)
Lithium
Caution
Li3s 1.2A 12.69V
FAS 022:43 00682
4.09 4.09V 4.09V
0.00 0.00V 0.00V
First, select the correct battery type by following the instructions on page 13.
Once you have set the correct battery type, press the ■ button once to return
to the “USER SET PROGRAM->“ screen. Press the ■ button again to enter the
“PROGRAM SELECT“ screen. On this screen you should
see the type of battery you have selected.
Press the ► button once to enter the “
CHARGE“ screen.
Now use the ✚ or
▬
buttons to change the charge
mode to FAST CHG. Press the ► button again and the amp rate value will
begin  ashing. Use the ✚ or
▬
buttons to adjust the value to the desired rate.
Follow the instructions provided with your battery when setting the amp rate.
Press the ► button again and the voltage value will begin  ashing. Use the ✚
or
▬
buttons to adjust the value to the desired rate. The voltage and cell count
should match the values listed on the battery label.
You are now ready to begin charging. Press and hold the ► button until you
see “
BATTERY CHECK WAIT...” followed by the “CONFIRM/CANCEL“ screen.
This screen displays the number of cells you set up as
”
R” and the number of cells detected by the processor
as “S”. If both numbers are identical, you may press and hold the ► button to
con rm and begin charging. If these numbers do not match, press the ■ but-
ton to return to the previous screen to carefully check the number of cells of
the battery pack before proceeding.
LiPo FAST CHG
0.1A 3.7V(1S)
R:3SER S:3SER
CONFIRM(ENTER)
PROGRAM SELECT
LiPo BATT
