This function is for balancing the voltage of individual Lithium-polymer bat-
tery cells while charging. In order to use the Balance Mode, the battery must
have a balance lead. Charging in this mode is di erent from the normal modes
because the built-in processor monitors the voltage of each individual cell and
controls the input current fed into each cell in order to equalize the voltage.
Use of a balance adaptor with any battery that has a balance lead will improve
the performance and lifespan of your battery.
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU HAVE
READ AND UNDERSTAND ALL OF THE WARNINGS AND SEFETY INFOR
MATION CONTAINED ON PAGES 47.
See page 12 for the appropriate charging connections setup for this operation.
First, select the correct battery type by following the instructions on page 13.
Once you have set the correct battery type, press the ■ button once to return
to the “
USER SET PROGRAM->“ screen. Press the ■ button again to enter the
“PROGRAM SELECT“ screen. On this screen you should
see the type of battery you have selected.
Press the ► button once to enter the “
CHARGE“ screen.
Now use the ✚ or
▬
buttons to change the charge
mode to “BALANCE“. Press the ► button again and the amp rate value will
begin  ashing. Use the ✚ or
▬
buttons to adjust the value to the desired rate.
Follow the instructions provided with your battery when setting the amp rate.
Press the ► button again and the voltage value will begin  ashing. Use the ✚
or
▬
buttons to adjust the value to the desired rate. The voltage and cell count
should match the values listed on the battery label.
You are now ready to begin charging. Press and hold the ► button until you
see “
BATTERY CHECK WAIT...” followed by the “CONFIRM/CANCEL“ screen.
This screen displays the number of cells you set up as
”
R” and the number of cells detected by the processor
as “S”. If both numbers are identical, you may press the ► button to con rm
and begin charging. If these numbers do not match, press the ■ button to re-
turn to the previous screen to carefully check the number of cells of the battery
pack before proceeding.
Lithium Balance Charge Mode
Lithium
LiPo BALANCE
0.1A 3.7V(1S)
R:3SER S:3SER
CONFIRM(ENTER)
Warning
PROGRAM SELECT
LiPo BATT
