Lithium Charge Mode (cont.)
Lithium
Press the ► button once to enter the “
CHARGE” screen.
Press the ► button again and the amp rate value will
begin  ashing. Use the ✚ or
▬
buttons to adjust the value to the desired rate.
Follow the instructions provided with your battery when setting the amp rate.
Press the ► button again and the voltage value will begin  ashing. Use the ✚
or
▬
buttons to adjust the value to the desired rate. The voltage and cell count
should match the values listed on the battery label.
Choosing “
AUTO” for the voltage/cell count setting will allow the X1 to auto-
matically determine these settings. If you choose the “AUTO” setting be sure to
con rm that the correct cell count is displayed once charging begins.
You are now ready to begin charging. Press and hold the ► button until you
see “
BATTERY CHECK WAIT...” followed by the “CONFIRM/CANCEL“ screen.
This screen displays the number of cells you set up as
”
R” and the number of cells detected by the processor
as “S”. If both numbers are identical, you may press and hold the ► button to
con rm and begin charging. If these numbers do not match, press the ■ but-
ton to return to the previous screen to carefully check the number of cells of
the battery pack before proceeding.
Once charging has commenced, the charger will display
the following real-time information: Battery type/cell
count, charging current, battery voltage, charging time and charged capactiy.
DURING CHARGING, THE BATTERY SHOULD BE PLACED INSIDE A
FIREPROOF/RETARDANT BAG AND ON A FIRE PROOF SURFACE, AWAY
FROM OTHER COMBUSTIBLE OBJECTS.
If you are using a balance adapter, during charging you
may press the ✚ button to view the voltage of each
individual cell.
Once the battery is fully charged the screen will read “
FULL” and the charger
will emit a chiming sound. Press the ■ button to stop charging. You may press
the ■ button at any time during the charging process to stop charging.
LiPo CHARGE
0.1A 3.7V(1S)
R:3SER S:3SER
CONFIRM(ENTER)
Li3s 1.2A 12.69V
CHG 022:43 00682
4.09 4.09V 4.09V
0.00 0.00V 0.00V
Caution
