User Manual

19
Item Selection Description
Language English, German,
Italian and French
Menu language
Pause 1 - 60 Minutes
Pause setting between charge / discharge cycles
1 -60 minutes. This setting is typically only used with NiMH or NiCd
batteries
Time Cut-off ON/OFF
Activates the time limit safety function. The default is ON, it is not rec-
ommended to change this.
Time Limit 1 - 720 Minutes
When you start a charge process, the integral safety timer of the bat-
tery automatically starts running at the same time. This is programmed
to prevent overcharging the battery if it proves to be faulty, or if the
termination circuit cannot detect the battery is full. The value for the
safety timer should be generous enough to allow a full charge of the
battery.
Capacity
Cut-off
ON / OFF Activates the capacity limit cut-off safety function. Default is on.
Capacity
Cut-off
100-60,000mAh
This program sets the maximum charge capacity that will be supplied
to the battery during a charge. If the delta peak voltage is not detected
nor has the safety timer expired for any reason, this feature will auto-
matically stop the process at the selected capacity value. Default is
5000mAh.
Key Beep ON/OFF
Pause setting between charge / discharge cycles
1 -60 minutes. This setting is typically only used with NiMH or NiCd
batteries.
Buzzer ON/OFF Turns end of process melody on or off. Default is on.
Input Low 10.3 - 11.0V Users can change the DC Input low voltage warning as necessary.
The default value is 11.0V.
Int. Temp Displays the internal temperature of the charger.
Reset
Selecting this resets the charger to factory defaults and erases all the
previously set parameters. After selecting this, you have to press and
hold the START / ENT button for at least two seconds.
Version Displays the charger’s rmware version.
