Warning
BEFORE SELECTING A PARAMETER OPERATION, IT IS CRITICAL THAT YOU KNOW THE
TYPE OF BATTERY YOU ARE WORKING WITH AND WHAT THE MANUFACTURER
RECOMMENDATIONS ARE FOR CHARGING OR DISCHARGING. FAILURE TO FOLLOW THE
MANUFACTURERS RECOMMMENDATIONS CAN RESULT IN DAMAGE TO THE BATTERY
AND POSSIBLE EXPLOSION OR FIRE.
The following is a step-by-step guide for setting the battery parameters on the Power Peak D7. The screen
shots and operation templates shown are for the operation of a Li-Po BALANCE CHARGE program.
Refer to the Available Operations chart on page XX to setup your specic type of battery.
Whenever a parameter value in the program needs to be adjusted, scroll to it using the + or – buttons.
Highlight the value by pressing the START/ENT button; to change the value press the + or - buttons.
The new value will be stored by re-pressing the START/Enter button.
OPERATING THE CHARGER
BATTERY SELECT
With the arrow pointing to the battery parameters, press
START/ENT to highlight the battery type. Use the + or –
to cycle through the battery types, once you have selected
the battery type that you are working with, press START/ENT
to conrm and move onto the battery voltage prompt.
VOLTAGE SELECT
With the voltage value highlighted, use the + or – to increase
or decrease the voltage to match your battery’s voltage.
Press START/ENT to conrm and move onto the Battery
Capacity prompt.
CAPACITY SELECT
With the capacity value highlighted, use the + or – to
increase or decrease the capacity to match your battery’s
capacity. Press START/ENT to conrm. Now is a good time
to check to make sure the settings match that of
your battery.
[ 01 ] Memory Name...
LiPo 7.4 V 200mAh
Chg Current : 2.0mA
dChg Current : 1.0mA
dChg Volt : 3.2V/C
TVC Volt : 4.20 V
[ 01 ] Memory Name...
LiPo 7.4 V 200mAh
Chg Current : 2.0mA
dChg Current : 1.0mA
dChg Volt : 3.2V/C
TVC Volt : 4.20 V
[ 01 ] Memory Name...
LiPo 7.4 V 200mAh
Chg Current : 2.0mA
dChg Current : 1.0mA
dChg Volt : 3.2V/C
TVC Volt : 4.20 V
Note
THE VOLTAGE WILL INCREASE IN VALUE
BASED ON THE NOMINAL VOLTAGE OF A
SINGLE CELL.
