MENU STRUCTURE
The Memory Name menu is where the parameters
for charging or discharging batteries are dened. The
corresponding settings are then stored in the memory.
(See Page 14 for setting process parameters)
The Data View menu displays information pertaining to
the charging and discharging processes of a Lithium
chemistry battery. When a balancing cable is attached,
the screen will also display the voltage of the individual
cells as well as the highest and lowest cell value.
The User Setup menu allows the user to customize
certain features of Power Peak D7 (See Page 14 for more
information on the parameters and defaults).
STOP/ESC
button
STOP/ESC
button
Once plugged in, turn on the power switch, the charger briey displays Hitec Power Peak D7
then the Memory screen appears. Use the STOP/ESC button to scroll through the menus.
[01] Memory Name...
LiPo 7.4V 200mAh
Chg Current : 2.0mA
dChg Current : 1.0mA
dChg Volt :3.2V/C
TVC Volt :4.20V
[ User Setup ]
Language : English
Rest Time : 10 Min
Safety Cut : ON
Safety Time : 120 Min
Capa Cut : ON
Capa Value : 500mAh
Key Beep : ON
[ DATA VIEW ]
Main : 11.39 V
Max : 3.81V
Min : 3.79V
3.79 V 3.79 V 3.81 V
0.00 V 0.00 V 0.00 V
0.00 V
