User Manual

1
2
3
4
1.TECHNICAL VALUES
CONTROL SYSTEM
OPERATING VOLTAGE RANGE
OPERATING TEMPERATURE RANGE
TEST VOLTAGE
OPERATING SPEED
STALL TORQUE
OPERATING ANGLE
DIRECTION
IDLE CURRENT
RUNNING CURRENT
DEAD BAND WIDTH
CONNECTOR WIRE LENGTH
DIMENSIONS
WEIGHT
2.FEATURES
3-POLE FERRITE MOTOR
DUAL BALL BEARING
3.APPLICATIONS
:+PULSE WIDTH CONTROL 1500usec NEUTRAL
:4.8V TO 6.0V
:-20 TO +60 C
:45 /ONE SIDE PULSE TRAVELING 400usec
:CLOCK WISE/PULSE TRAVELING 1500 TO 1900usec
:300mm(11.81in)
:40.6x19.8x37.8mm(1.59x0.77x1.48in)
:AT 4.8V :AT 6.0V
37.8
27 17.3
40.6
48.4
19.8 10.2
:400mA :500mA
:5.5kg.cm(76.37oz.in)
:6.8kg.cm(94.43oz.in)
:8.8mA
:8usec
:9.1mA
:55.2g(1.94oz)
:0.18sec/60 AT NO LOAD
:0.15sec/60 AT NO LOAD
LONG LIFE POTENTIOMETER
3-METAL GEARS & 1-RESIN METAL GEAR
HYBRID I.C
AIRCRAFT TO 1/4 SCALE
30 TO 60 SIZE HELICOPTERS
STEERING AND THROTTLE FOR 1/10TH & 1/8TH ON-ROAD AND OFF-ROAD VEHICLES
53.4
ANNOUNCED SPECIFICATION OF
HS-625MG STANDARD DELUXE
HIGH SPEED SERVO
