User Guide

Speaker Systems for Hitachi Plasma Display Monitor CMP5000WX

Model

CMPAS05 User Manual

Parts Configuration Chart

■Confirming the parts provided

Before assembly, check to make sure that none of the parts provided are missing.

READ THE INSTRUCTIONS ON THIS USER MANUAL CAREFULLY.

KEEP THIS USER MANUAL FOR FUTURE REFERENCES.

DO NOT HANDLE THE MONITOR BY HOLDING THE SPEAKER SYSTEMS.

CAUTION

• Speaker mounting fittings

• Speaker cable (27 cm) x 2

• Mounting tool (Hex wrench)

For top right

side x 1

For top left side x 1

For bottom x 2

• Speaker mounting bolts

Flat countersunk head screw x 4

Hexagon socket head screw x 4

Washer M8 ( ø 25) x 2

• Mounting plate

For right

side x 1

For left

side x 1

NOTE:

•Always use the accessory mounting

fittings for installation.

•When screws other than those enclosed

as accessories are used to install the

speakers, the speakers may drop off or

accidents may be caused. Always use

the screws enclosed as accessories.

Please handle the speakers with sufficient care, as the grille net and the cabinet can become

damaged or broken when they are subjected to strong external impacts.

CAUTION
